HL-EC Series T8 LED Tubes
Features
• Active PFC >0.9 and THD < <%20 with input filtering circuits
• Up to 3430 lm
• Up to %60 energy saving
• Aluminum heatsink
• Flicker free
• 3 SCDM color tolerance
• Up to 170 lm/W efficacy
• New-gen high efficiency LEDs
• Low maintenance cost
• EN62560 certified
• CRI >80
• Min 50.000 on/off cycles
Applications
• All general lighting applications
• Closed luminaires
Options
• Metal end cap
• 2700K, 5700K, meat color
• Active PFC >0.9 and THD < <%20 with input filtering circuits
• Up to 3430 lm
• Up to %60 energy saving
• Aluminum heatsink
• Flicker free
• 3 SCDM color tolerance
• Up to 170 lm/W efficacy
• New-gen high efficiency LEDs
• Low maintenance cost
• EN62560 certified
• CRI >80
• Min 50.000 on/off cycles
Applications
• All general lighting applications
• Closed luminaires
Options
• Metal end cap
• 2700K, 5700K, meat color
Light Distributions
Dimensions
| A | B | C | Weight | |
|---|---|---|---|---|
| HL15 Series | 1499mm | 1513mm | 28mm | 472gr |
| EC12 Series | 1199mm | 1213mm | 28mm | 355gr |
| EC09 Series | 893mm | 907mm | 28mm | 275gr |
| EC06 Series | 589mm | 603mm | 28mm | 200gr |
HL Series 1500mm T8 LED Tubes
| Product ID | Energy Class | Power | PFC | Life Hrs | Operating Temp. | Light Flux | Front Cover | Color Temperature |
|---|---|---|---|---|---|---|---|---|
| HL15-180-65T |  |
20.0W | 0.90 | 60.000 | -30C +45C | 3430LM | Transparent | 6500K |
| HL15-180-40T | |
20.0W | 0.90 | 60.000 | -30C +45C | 3430LM | Transparent | 4000K | HL15-180-30T |  |
20.0W | 0.90 | 60.000 | -30C +45C | 3260LM | Transparent | 3000K | HL15-180-65F | |
20.0W | 0.90 | 60.000 | -30C +45C | 3100LM | Opaque | 6500K | HL15-180-40F | |
20.0W | 0.90 | 60.000 | -30C +45C | 3100LM | Opaque | 4000K | HL15-180-30F | |
20.0W | 0.90 | 60.000 | -30C +45C | 2940LM | Opaque | 3000K |
EC Series 1200mm T8 LED Tubes
| Product ID | Energy Class | Power | PFC | Life Hrs | Operating Temp. | Light Flux | Front Cover | Color Temperature |
|---|---|---|---|---|---|---|---|---|
| EC12-088-65T |  |
18.0W | 0.90 | 60.000 | -30C +45C | 2860LM | Transparent | 6500K |
| EC12-088-40T | |
18.0W | 0.90 | 60.000 | -30C +45C | 2860LM | Transparent | 4000K |
| EC12-088-30T | |
18.0W | 0.90 | 60.000 | -30C +45C | 2730LM | Transparent | 3000K |
| EC12-088-65F | |
18.0W | 0.90 | 60.000 | -30C +45C | 2600LM | Opaque | 6500K |
| EC12-088-40F | |
18.0W | 0.90 | 60.000 | -30C +45C | 2600LM | Opaque | 4000K |
| EC12-088-30F |  |
18.0W | 0.90 | 60.000 | -30C +45C | 2470LM | Opaque | 3000K |
EC Series 895mm T8 LED Tubes
| Product ID | Energy Class | Power | PFC | Life Hrs | Operating Temp. | Light Flux | Front Cover | Color Temperature |
|---|---|---|---|---|---|---|---|---|
| EC09-066-65T |  |
13.0W | 0.90 | 60.000 | -30C +45C | 2100LM | Transparent | 6500K |
| EC09-066-40T | |
13.0W | 0.90 | 60.000 | -30C +45C | 2100LM | Transparent | 4000K |
| EC09-066-30T | |
13.0W | 0.90 | 60.000 | -30C +45C | 2000LM | Transparent | 3000K |
| EC09-066-65F | |
13.0W | 0.90 | 60.000 | -30C +45C | 1900LM | Opaque | 6500K |
| EC09-066-40F | |
13.0W | 0.90 | 60.000 | -30C +45C | 1900LM | Opaque | 4000K |
| EC09-066-30F |  |
13.0W | 0.90 | 60.000 | -30C +45C | 1800LM | Opaque | 3000K |
EC Series 590mm T8 LED Tubes
| Product ID | Energy Class | Power | PFC | Life Hrs | Operating Temp. | Light Flux | Front Cover | Color Temperature |
|---|---|---|---|---|---|---|---|---|
| EC06-048-65T |  |
9.0W | 0.90 | 60.000 | -30C +45C | 1430LM | Transparent | 6500K |
| EC06-048-40T | |
9.0W | 0.90 | 60.000 | -30C +45C | 1430LM | Transparent | 4000K |
| EC06-048-30T | |
9.0W | 0.90 | 60.000 | -30C +45C | 1360LM | Transparent | 3000K |
| EC06-048-65F | |
9.5W | 0.90 | 60.000 | -30C +45C | 1300LM | Opaque | 6500K |
| EC06-048-40F | |
9.0W | 0.90 | 60.000 | -30C +45C | 1300LM | Opaque | 4000K |
| EC06-048-30F |  |
9.0W | 0.90 | 60.000 | -30C +45C | 1235LM | Opaque | 3000K |
