5001 Series LED Street Luminaire
Features
• Shock proof tempered glass
• IP66 ingress protection
• 50.000 hrs L70 performance
• Passive cooling with aluminum injection body
• Up to %50 energy saving
• 220-240V input voltage, 4kV surge withstand
• Active PFC >0.95 and THD < %10 with input filtering circuits
• EN60598 compliant
• 3000K, 4000K, 6000K, CRI >70
• -30C +50C operating temp.
• Suitable for 46-55mm diameter console poles
Applications
• Outdoor lighting, street lighting
Options
• 2700K, 5700K, >80 CRI
Product ID Power Light Flux Weight
5001-145 45.0W 5200LM 5420gr
5001-160 60.0W 6700LM 5420gr
5001-175 75.0W 8200LM 5420gr
